Description

1200.2 EVO 5

The 1200.2 EVO 5 is a compact, modern amplifier that delivers 1200W RMS of power distributed over 2 channels.

The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.

Available in:

• 2 Ohm
• 4 Ohm

General Specifications

+

• 1200.2 EVO 5 – 2 OHMS

  Power @ 1Ω: 2 X 600W RMS
  Power @ 2Ω: 2 X 402W RMS
  Power @ 4Ω: 2 X 269W RMS
  Bridge Power @ 2Ω: 1 X 1200W RMS
  Bridge Power @ 4Ω: 1 X 804W RMS

• 1200.2 EVO 5 – 4 OHMS

  Power @ 1Ω: N/A
  Power @ 2Ω: 2 X 600W RMS
  Power @ 4Ω: 2 X 402W RMS
  Bridge Power @ 2Ω: N/A
  Bridge Power @ 4Ω: 1 X 1200W RMS

• Operating Voltage:

  2Ω: 10V ~ 16V
  4Ω: 10V ~ 16V

• Current Draw (Max)

  2Ω: 137.6A
  4Ω: 129.6A

• Current Draw (Music)

  2Ω: 68.8A
  4Ω: 64.8A

• Recommended Fuse (Music):

  2Ω: 70A
  4Ω: 70A

• Total Efficiency:

  2Ω: 79.88%
  4Ω: 77.78%

• Damping Factor:

  2Ω: 200
  4Ω: 200

• Frequency Response (-3dB):

  2Ω: 10Hz ~ 20kHz
  4Ω: 10Hz ~ 20kHz

• SNR:

  2Ω: 102.15dB
  4Ω: 2105.44dB

• Crossover

  HPF: 80Hz
  LPF: 80Hz

• Width:

  5.3 in / 13,6 cm

• Length:

  6.7 in / 17 cm

• Height:

  2.1 in / 5,5 cm

• Weight:

  2.5 ib / 1,13 Kg
