Audison Voce AV K6 High-Fidelity Component Speakers

Description

The prestigious Eisa Award “European In-Car Speaker System 2010-2011” was bestowed to the AV K6 and AV K5 kits, which gather and comprise the most advanced technologies developed for the Audison components, at the service of music.
The whole R&D laboratory’s experience was poured into the design of these precious components, to create a synergy that can offer the highest quality sound in terms of bandwidth, dynamics of the musical message, naturalness and richness of details. The new reference for their own category.

FEATURES

• TWEETER1 Tetolon dome, a combination of silk and cotton with
  proprietary damping treatment, provides low mass and
  resonance-free response up to ultrasonic frequencies.
• CCAW (Copper Clad Aluminium Wire) voice coil wound on
  double layer, extremely lightweight and compact, resulting
  in a very high efficiency and a crisp, dynamic sound.
• The annular geometry of the Rear Damping Chamber,
  together with the proprietary damping material, extends
  the frequency response to lower limits and reduces
  harmonic distortion.
• High flux density Neodymium magnet, for very high
  efficiency and detailed sound.

WOOFER

• The profile of the aerodynamic basket’s spokes along
  with the open-air design ensure drastic reduction of
  back-wave reflections.
• The exclusive Butyl rubber Triple Wave surround
  profile provides full linearity as well as reliable
  performance under extreme conditions.
• Extremely lightweight and compact, the CCAW (Copper
  Clad Aluminium Wire) voice coils wound on double layer
  provide very high efficiency and neat, dynamic sound.
• Cotton-fibre pressed pap


  TECHNICAL SPECS

  Woofer Size	165 mm
  Tweeter Size	28 mm
  Woofer Voice Coil Diameter	30 mm
  Tweeter Voice Coil Diameter	28 mm
  Magnet Size Woofer	90 x 40 x 15
  Power Handling – Peak	250 W
  Power Handling – Continuous	125 W
  Sensitivity	91 dB
  Impedance	4 Ohm
  Frequency Response	50 ÷ 22k
  Crossover Woofer	Lo/Hi-Pass 2.5 kHz @ 12/12 dB/Oct.
  Adjustment Tweeter Level	+2; 0; -2 dB
  Woofer Cone Diameter	130 mm
  Xmax Woofer	3 mm

  ELECTRIC-ACOUSTIC SPECS

  Re Woofer	3.5 Ohm
  Fs Woofer	68 Hz
  Le Woofer mH @ 1 kHz	0.31
  Vas Woofer	8.2 l
  Mms Woofer	16.1 g
  Cms Woofer	0.34
  Bxl Woofer	5.5
  Qts Woofer	0.74
  Qms Woofer	7.84
  Spl Woofer	91 dB

  GENERAL

  Weight Woofer	1.2 kg
  Weight Tweeter	0.07 kg

  er cone with treatment.

• The Radial Venting System ensures high thermal
  capability, power handling and reliability
